3+10 Pin Hybrid Power Connector for EV Charging and BMS Communication (Male/Female)

3+10 Pin Hybrid Power Connector for EV Charging and BMS Communication (Male/Female)

Product Definition

This 3+10 Series connector is a high-density hybrid interconnect system designed for electric vehicles and intelligent battery management. It features 3 large power terminals for primary current transmission and 10 small signal pins for multi-channel BMS data exchange. Engineered for reliability, it supports up to 5000 mating cycles and provides a secure, flame-retardant connection for complex power systems.

Custom Attributes

• Product Name: 3+10 Pin EV Power & Signal Connector
• Connector Gender: Male Plug and Female Socket Set
• Number of Pins: 13 Pins (3 Power + 10 Signal)
• Housing Material: High-grade UL94 V0 Flame Retardant Plastic
• Mounting Dimensions: 58mm x 50mm Panel Mount (Female)
• Application: E-bike, Electric Motorcycle, BMS, Charging Station

Parameter and Techinical Information chart below

Core Value & Points:

1. High Load Capacity: Specifically engineered to handle up to 20A current on power pins, suitable for fast-charging applications.
2. Reliable Signal Integrity: Five dedicated signal pins ensure stable data transmission for Battery Management Systems (BMS).
3. Enhanced Safety: Features UL94 V0 flame retardancy and a high insulation resistance of ≥100mΩ to prevent electrical hazards.
4. Industrial Durability: Rated for 3000+ mating cycles, offering a long service life even with daily plugging and unplugging.
5. Precision Fit: Controlled insertion force (20-60N) ensures a secure connection that is resistant to vibration during vehicle motion.

Usage Scenarios

• E-Mobility: Primary charging and discharging port for electric bicycles, scooters, and motorcycles.
• Battery Modules: Interconnection for lithium battery packs and power exchange cabinets.
• Energy Storage: Power interface for portable outdoor power stations and home energy storage systems.
• Industrial Power: Suitable for automated equipment requiring combined power and signal transmission in compact spaces.
